Genalog Limited

Genalog & Omnetics @ Space-Comm 2026

Duncan Browne — Tue, 17 Feb 2026 14:29:31 +0000

Omnetics Connector Corporation has a rich history of supporting orbital and deep space projects

Their connectors have been used on traditional and commercial Space Shuttles, multiple Mars Rovers, the Hubble Telescope and countless Earth-Orbiting Satellites. For decades, Omnetics connectors have helped design engineers tasked with developing the next break-through in space history.

Omnetics’ New Connector Design and Materials Teams are centrally focused on low weight, high density and rugged superiority to meet the extreme reliability demands during launch through deep space operations. Special “rugged-mount” designs can be made to system configurations. Materials have been selected for thermal-expansion match to sustain continued performance from launch pad through geo-thermal orbit conditions. With increased densification of space cables and reduced connector size, Micro and Nano-scale interconnect systems offer significantly reduced weight and lower payload costs. Omnetics design teams will also help with unique cable requirements to solve EMI, cross-talk and high speed problems. Backshells, strain-reliefs, braided shields and special cables are all available to improve handling and extend life in your system. Contact Genalog to discuss your requirements.

Omnetics offers multiple levels of space screening to the requirements of your specific application.

The post Genalog & Omnetics @ Space-Comm 2026 appeared first on Genalog Limited.

ODU USB-C Bridging Civilian & Military Requirements

Duncan Browne — Tue, 28 Oct 2025 10:41:35 +0000

ODU AMC® High-Density as a solution

As a counterpart to the standard interface, ODU offers their AMC® High-Density miniature circular connectors – space saving and powerful for power and data rates.

High contact density allows for high currents in a small space, making them ideal for mobile military systems. The robust design was developed for connection under extreme conditions and can withstand even strong vibrations, moisture, dust and considerable temperature fluctuations from -40° C to +85° C.

With IP68 / IP6K9K, the system is also permanently protected against the ingress of water, even during high-pressure cleaning or submersion. Furthermore, the seamless EMC shielding ensures reliable signal transmission even with high electromagnetic interference.

A break-away function enables quick disconnection in an emergency – alternatively, an additional screw-lock function ensures robust permanently fixed positions.

But that is not the end of the USB saga

Military equipment is undergoing a huge transformation, with a proliferation of small COTS devices, often connected/charged via a standard USB-C socket.

So, what is now needed is an ‘umbilical’ link between base equipment and the various hand-held devices. ODU now offers just such a pragmatic solution:

ODU AMC® High-Density to USB-C interface umbilical

ODU AMC® High-Density 12.8mm diameter connector at one end and a right-angled over-moulded USB-C plug at the other - crucial for mobile systems.
Maximum flexibility and convenience thanks to cable lengths of up to 4 metres.
Power transmission up to 5A and data rates up to 480 Mbit/s
Robust design for -40° C to +85° C and 5,000 mating cycles

This umbilical offers the best possible solution – retaining the high integrity of the connection to base equipment while providing the most rugged connection to the small ancillary devices.

The post ODU USB-C Bridging Civilian & Military Requirements appeared first on Genalog Limited.

Omnetics High-Speed

Duncan Browne — Thu, 09 Oct 2025 07:00:38 +0000

Choose from standard part numbers, filter by chosen attributes

The High-Speed Nano-D uses modified insulators and pin arrangements to optimize impedance and performance for high-speed or high-density signal routing. 1 Amp pre-wired parallel pair cable and PCB solutions deliver up to 20 Gbps performance per differential pair. High-Speed connectors and cables are optimized for gigabit digital applications and protocols such as: USB 3.0, 10GbE, Camera Link, and PCIe. These high performance Mil-Aero style Nano-D connectors are built using Omnetics MIL-DTL-32139 compliant Flex Pin contact solution.

The High-Speed connector solutions have the ability to withstand high shock and vibration while maintaining signal integrity.

Turnkey pre-wired factory cables and PCB connector solutions. Unique contact isolation and spacing for optimal performance up to 20 Gbps. Uses 30 AWG parallel pair High-Speed cable. 1 Amp Flex Pin contacts performance in high vibrations and shock environments.

Electro-Mechanical Specifications
TYPE	PERFORMANCE
Durability	> 2000 Mating Cycles min
Temperature	-55ºC to +125 ºC
Current rating	1 Amp per contact
Voltage Rating (DWV)	250 VAC RMS Sea Level
Insulation Resistance	5,000 Megohms @ 100 VDC
Shock	100 g’s discontinuity < 10 nanoseconds
Vibration	20 g’s discontinuity < 10 nanoseconds
Thermal Vacuum Outgassing	1.0% max TML, 0.1% VCM
Contact Resistance	71 milliohms (71 mV) max @ 1 Amp
Mating/Unmating Force	2.5 oz. (.71g) typical per contact

Material Specifications
Contact	Copper Alloy Per MIL-DTL-32139
Contact Finish	Gold per ASTM B488, Type II, Class 1.27, Code C Over Nickel Underplate
Insulator	LCP Per MIL-DTL-32139 Or PEEK
Encapsulant	Epoxy

Shell Options
Aluminium 6061	Electroless Nickel per SAE-AMS-2404
Stainless Steel, 300 Series	Passivated per SAE-AMS-2700

The post Omnetics High-Speed appeared first on Genalog Limited.

Harwin PCN – Manufacturing method for Datamate vert SMT Connectors

Duncan Browne — Fri, 29 Aug 2025 13:31:41 +0000

The post Harwin PCN – Manufacturing method for Datamate vert SMT Connectors appeared first on Genalog Limited.

KONA Horizontal – Harwin extend high power connector range

Duncan Browne — Tue, 01 Apr 2025 09:57:54 +0000

The post KONA Horizontal – Harwin extend high power connector range appeared first on Genalog Limited.

Harwin expand Kontrol range to SIL

Duncan Browne — Fri, 07 Mar 2025 15:43:02 +0000

Introducing the New Single-Row 1.27mm Kontrol Connectors and Cable Assemblies

Harwin and Genalog are very excited to announce an expansion of our Kontrol range of industrial board-to-board interconnects (BBi). By adding single row connectors and cables to the 1.27mm pitch (0.05") connectors. The range has been created to bridge the gap between high-end connectors and established pin header and socket solutions.

The launch adds to their existing dual-row Kontrol connectors, extending the range with 49 new products. These are now 21 SMT connectors and 28 double-ended cable assemblies that include pin-count options of 2, 3, 4, 6, 8, 10 and 12.

SMT Connectors

All new SMT connectors in the series are available in vertical (male only) or horizontal (male and female) mounting options. They are manufactured to include full shrouding and recessed contacts incorporated to prevent damage to the pins.

Additionally, to improve assembly, the connectors have been polarized to prevent mis-mating. They also feature a tolerance to misalignment, with a permissible linear misalignment of up to 0.075mm and an allowable misalignment angle of 4.3o.

The latched design enables tool-free mating and unmating, while surface mount tabs have been implemented to improve the retention force holding the connectors to the PCB. Location pegs have also been incorporated to assist with correct board placement and inhibit movement while soldering.

Double-Ended Cable Assemblies

The new Kontrol male and female double-ended cable assemblies include in-line connectors and UL-Specification 26 AWG ribbon cable, with an option of 150mm and 300mm options available.

Like the SMT connectors, full shrouding, latches and polarization have been implemented to protect contacts and improve secure and blind mating.

Technical Specifications and Availability

These new single row products meet the same high electrical and reliability specifications as the existing Kontrol line-up showcasing a current rating of 1.2A per contact, and a 25mΩ contact resistance.

The connectors are qualified up to 500 mating operations. These were operated across a 170oC temperature range (-55 to +125oC, board-to-board / -20 to 105oC cable-to-board and cable-to-cable) and have been tested to withstand vibration forces of 20 G for up to 12 hours.

All connectors are available in tape and reel packaging for automated assembly processes, with disposable pick-and-place caps included where needed.

John Feaster, Harwin’s BBi product manager said: “Industrial and embedded applications are needing to operate under ever more stringent conditions, deployed with tighter constraints on space and in harsher environments.

These new single row Kontrol connectors and cable assemblies give designers the greater flexibility they need when creating designs that exceed both today’s and future requirements.”

The post Harwin expand Kontrol range to SIL appeared first on Genalog Limited.

ODU Focus Article – The evolution of military optronics

Duncan Browne — Fri, 28 Jun 2024 13:03:57 +0000

Optronics form an integral part of today’s operational military equipment, playing a decisive role in the tactical superiority and safety of armed forces. From night vision technology and thermal imaging to enhanced head-up displays (HUDs) and augmented reality glasses, these optoelectronic systems are now indispensable tools.

However, the use of such highly sophisticated optronics in extreme environments and the high sensitivity of such systems, present manufacturers with special challenges.

In particular, the interfaces and connections of the optronics are a potential weak point.

These connectivity challenges are detailed below.

1. Break resistance: The connection systems have to withstand enormous tensile and
torsional forces, which can lead to bent or broken contacts. Conventional push-pull mechanisms increase the leverage on the connection, due to their design.

Therefore, to meet the requirements of highly innovative optronics, ODU has developed best-in-class ODU-AMC® connectors that are many times more robust than conventional half-shell coded systems. They offer reliable protection against twisting and breakage, enabling the transmission of various data protocols for imaging applications such as HDMI.

2. Environmental protection: For a solution that can be used as flexibly as possible, the interfaces and connections of the optronics must be able to withstand extreme levels of dust, water and shock - ODU connectors meet the highest environmental standards. With an immersion depth of up to 20 metres and protection classes IP6K8 and IP6K9K. This makes them ideally suited for use in harsh environments without reducing the performance of the optronics

3. Hermetic sealing: Optronics are often filled with inert gas, such as nitrogen or argon, to eliminate an oxygen-containing atmosphere. Vacuum‐tight connector systems with glass potting technology for extremely high pressures are available from ODU.

4. The smallest foot-print: Naturally, all of the above have to be achieved, together with the ability to lock securely, in the most confined spaces – The ODU-AMC® connectors are designed specifically for this situation.

ODU - an experienced provider of interconnectivity

ODU offers comprehensive support for vision system and accessory OEM’s.

The solutions available enable improved cross-platform functionality including

STANAG 4695 connection to portable battery systems (PDUs) for soldiers.

ODU has many years of experience and is a proven supplier for major OCCAR procurement projects in the field of night vision equipment for the German and Belgian armed forces. ODU is also the main supplier for one of the largest projects for the integration of augmented reality in the US armed forces.

Through decades of collaboration with customers, ODU offers extensive experience in the development of customized connection solutions.

The post ODU Focus Article – The evolution of military optronics appeared first on Genalog Limited.

New franchised partner for Genalog – Amokabel

Duncan Browne — Mon, 24 Jun 2024 15:55:07 +0000

Speaking on behalf of Genalog was Sales Director Paul Bennett (left);

"In offering UK manufactured UL and PTFE cable and wire, as well as their industry specific ranges from Sweden, Amokabel are uniquely positioned to meet the demands of busy OEM engineers and when the supply chain in general struggles against the current global climate. We look forward to working closely together to support the existing and new client base."

Marc Pawson (Sales Director for Amokabel - right) added "This exciting new partnership makes excellent commercial sense due to Genalog's leading supply chain solutions for their customers, from the bespoke stock holding offerings of over 12 months, to the personal and dedicated sales contact service for every account. I look forward to growing the UK market together."

Amo Special Cables Limited

UL (various)

BS3G210 (PTFE)

DEF-STAN 61-12 PART 33/001

In Amokabel UKs factory in Leigh, they specialize in the manufacture of high-temperature cable designed to withstand extreme conditions at high temperatures, flames, and chemicals.

They have a wide range of products including PTFE wires and ETFE thermocouple cables for temperature sensing, and flame-retardant cables for use in mass transit. Amokabel also offer multi-conductor copper and fiber optic cables for applications in energy, industrial, and defense sectors.

Together Genalog and Amokabel will be servicing the below industry sectors as well as anywhere quality and realiable cable and wire is required.

Amokabel Flexishield Ltd

In Mansfield, Amokabel manufacture cables that are designed to be concealed in walls and building spaces less than 50mm deep.

Its main feature is the safety mechanism that activates upon penetration by sharp metal objects, causing the cable to safely break at 200 amperes under such conditions. This allows for the activation of an MCB up to 40A type B or up to 20A type C, exceeding BS8436 requirements. The cable uses a bonded aluminium tape for excellent mechanical resistance and effective reduction of electrical interference.

The post New franchised partner for Genalog – Amokabel appeared first on Genalog Limited.

Genalog awarded distributor of the year 2023 by Omnetics Connector Corp

Duncan Browne — Thu, 11 Apr 2024 15:35:37 +0000

Genalog Ltd is proud to announce that it has been awarded distributor of the year for 2023 by Omnetics Connector Corp. Speaking whilst accepting the award at Omnetics head office in Minneapolis USA, Genalog Director Paul Bennett said that “Yet again the dedication and achievements of the Genalog team have paid dividends in terms of greatly increasing not just sales figures but also the design potential of bourgeoning industry sectors that require hi-rel and ultra-rugged interconnect”. Genalog looks forward to continuing this close relationship with the esteemed franchised connector manufacturer in the coming years.

The post Genalog awarded distributor of the year 2023 by Omnetics Connector Corp appeared first on Genalog Limited.

binder Medical Article: Connectivity in Patient Monitoring

Duncan Browne — Wed, 20 Mar 2024 16:19:08 +0000

Patient monitoring refers to observing, tracking, and analyzing a patient's health and relying that information to and between healthcare providers. In real-time, monitoring devices can detect deviations from baseline health parameters and notify healthcare providers when intervention may be necessary. On an ongoing basis, data from these devices helps medical professionals analyze patterns and detect early signs of deterioration or other developments.

Medical monitoring is primarily used in clinical settings, including intensive care units, operating rooms, and post-anesthesia care units. However, recent innovations enable remote patient monitoring, allowing patients to remain at home or in other non-clinical settings while staying connected to healthcare providers. Remote patient monitoring devices, remote patient monitoring systems, and health monitoring devices have the potential to support doctors and hospitals while optimizing the health care system. binder medical connector ranges....

The post binder Medical Article: Connectivity in Patient Monitoring appeared first on Genalog Limited.
